T50 Spreading
Official DJI parts diagram and material list.
Pricing is per single item unless the part description says otherwise.
| No. | Part | $ Each (inc. GST) | |
|---|---|---|---|
| 1 | Baffle YC.JG.ZS003497 | — | |
| 2 | Screw M30-HC080080-55-85 YC.WJ.L00868 | $3.05 | |
| 3 | Sensing Part YC.JG.ZS003512 | — | |
| 4 | Reduction Gearbox Motor Dustproof Cover YC.JG.MY000387 | $6.60 | |
| 5 | Screw M25-HC01200120-045025-5103-Y YC.WJ.L00006 | $1.38 | |
| 6 | Spinner Disk Gasket YC.JG.BJ000776 | — | |
| 7 | R-Type Thumb Nut YC.JG.QX003398 | — | |
| 8 | R-Type Thumb Nut YC.JG.QX003398 | — | |
| 9 | Spinner Disk YC.JG.ZS003426 | — | |
| 10 | Spinner Disk_Upper Disk Buckle YC.JG.ZS003513 | — | |
| 11 | Screw M30-HC080080-55-85 YC.WJ.L00868 | $3.05 | |
| 12 | Spinner Disk_Upper Disk YC.JG.ZS003480 | — | |
| 13 | Agitator BC.AG.SS000715 | — | |
| 14 | Large Gear YC.JG.ZS003515 | — | |
| 15 | Short Shaft YC.JG.QX003086 | — | |
| 16 | Spreading Flange YC.JG.QX003085 | — | |
| 17 | Upper Thread 3*3 YC.WJ.L00005 | — | |
| 18 | Sealing Sleeve YC.JG.QX002222 | — | |
| 19 | Dustproof Cover 1 YC.JG.MY000731 | — | |
| 20 | Dustproof Cover 3 YC.JG.MY000733 | — | |
| 21 | Hopper Gate BC.AG.SS000714 | — | |
| 23 | Dustproof Hood 2 YC.JG.MY000732 | — | |
| 24 | Reduction Gearbox BC.AG.SS000716 | — | |
| 25 | Screw M30-HB050045-55-05 YC.WJ.LL000096 | — | |
| 26 | Lubricating Ring YC.JG.QX001324 | — | |
| 27 | Screw M30-HB050045-55-05 YC.WJ.LL000096 | — | |
| 28 | Hopper Gate Foam Pad YC.JG.MQ001943 | — | |
| 29 | Screw M30-HC080080-55-85 YC.WJ.L00868 | $3.05 | |
| 30 | Heat Sink Sealing Ring YC.JG.MY001031 | — | |
| 31 | Spreading Signal Cable YC.XC.XX001005 | — | |
| 32 | Control Module BC.AG.SS000713 | — | |
| 33 | Cable Board Sealing Ring YC.JG.MY001030 | — | |
| 34 | Screw M40-HC00450039-076020-0003-Y YC.ST.LL000112 | $2.00 | |
| 35 | Drain Hole Waterproof Ring YC.JG.MY000314 | $2.50 | |
| 36 | T30-HC080065-60-15 YC.WJ.LL000074 | — | |
| 37 | Servo Sealing Ring YC.JG.MY000341 | — | |
| 38 | Spinner Disk BC.AG.SS000718 | — | |
| 39 | Servo Module BC.AG.SS000717 | — | |
| 40 | Screw M30-HC060060-55-85 YC.WJ.L00870 | $2.05 | |
| 41 | Lock Button Spring YC.JG.TT000163 | — | |
| 42 | Spread Tank Lock Button YC.JG.QX003018 | — | |
| 43 | Fixing Knob YC.SJ.WS001064 | — | |
| 44 | Screw M30-HC080080-55-85 YC.WJ.L00868 | $3.05 | |
| 45 | Spray System_ Locking Device EVA Foam YC.BZ.XX000417 | — | |
Large Gear STD T25 & T50 YC.JG.ZS002414 | — | ||
Teflon Pad YC.JG.MQ001323 | — | ||
Agitator--T20P&T25&T40 BC.AG.SS000607 | — | ||
Axis Clip YC.JG.BJ000694 | — | ||
Spray Tank Lock YC.WJ.ZZ000968 | — | ||
Fixing Spring YC.WJ.TT000078 | — | ||
Spray System_ Locking Device Sticker--T20P&T40 YC.BZ.JJ000329 | — |
Can't spot your part? Search by part number on the search page or call 1300 916 075.
