T25P Flow Meter
Official DJI parts diagram and material list.
Pricing is per single item unless the part description says otherwise.
Parts Diagram
Hover a number to match it with the list. Double-click or use + to zoom.
| No. | Part | $ Each (inc. GST) | |
|---|---|---|---|
| 1 | Flow Meter Water Outlet Hose YC.JG.JS000033 | — | |
| 2 | Thumb Nut YC.JG.ZS003594 | — | |
| 3 | One-Way Valve Core Straight Connector YC.JG.ZS004721 | — | |
| 4 | Hose Nut YC.JG.ZS002255 | — | |
| 5 | One-Way Valve Sealing Ring YC.JG.MY001129 | — | |
| 6 | One-Way Valve Core Sealing Ring YC.JG.MY001329 | — | |
| 7 | One-Way Valve Core YC.JG.ZS005001 | — | |
| 8 | One-Way Valve Spring YC.JG.TT000210 | — | |
| 9 | One-Way Valve Core Curve Connector YC.JG.ZS004722 | — | |
| 10 | Flow Meter Signal Cable YC.XC.XX001004 | — | |
| 11 | Hose Nut YC.JG.ZS002255 | — | |
| 12 | Flow Meter Module (Incl. Signal Cable) BC.AG.SS000927 | — | |
| 13 | Flow Meter Water Inlet Hose YC.JG.JS000032 | — | |
| 14 | Thumb Nut YC.JG.ZS003594 | — | |
| Thumb Nut YC.JG.ZS006171 | $2.30 | ||
| Single Connector Rubber Stopper YC.JG.ZS006115 | $3.10 | ||
| One-Way Valve Spring YC.JG.TT000285 | $1.71 | ||
| Valve Core Sealing Ring YC.JG.MY001775 | $9.00 | ||
| One-Way Valve Sealing Ring YC.JG.MY001774 | $1.55 | ||
| One-Way Valve YC.JG.ZS006170 | $7.55 | ||
| Hose Nut YC.JG.ZS006165 | $1.55 | ||
| Flow Meter Adapter YC.JG.ZS006199 | $3.10 | ||
| Flow Meter Adapter Sealing Ring YC.JG.MY001790 | $4.55 | ||
| Flow Meter Module BC.AG.SS001031 | $634.50 | ||
| Flow Meter Water Outlet Hose YC.JG.JS000080 | $12.00 | ||
| Hose Y-tee Part YC.JG.ZS006644 | $6.65 | ||
| Flow Meter Water Inlet Hose YC.JG.JS000088 | $10.85 |
Can't spot your part? Search by part number on the search page or call 1300 916 075.
