T25P Spray Lance
Official DJI parts diagram and material list.
Pricing is per single item unless the part description says otherwise.
Parts Diagram
Hover a number to match it with the list. Double-click or use + to zoom.
| No. | Part | $ Each (inc. GST) | |
|---|---|---|---|
| 1 | Spray Lance Shell YC.JG.ZS004506 | — | |
| 2 | Sprinkler Soft Hose YC.JG.JS000043 | — | |
| 3 | Solenoid Valve Module BC.AG.SS000871 | — | |
| 4 | Centrifugal Sprinkler Lower Disk YC.JG.ZS004923 | — | |
| 5 | R-Type Pin YC.JG.TT000203 | $0.90 | |
| 6 | Sealing Ring (ID=16.5 mm) YC.JG.MY001295 | — | |
| 7 | Centrifugal Sprinkler Nut YC.JG.ZS004510 | $1.76 | |
| 8 | Centrifugal Sprinkler Upper Disk YC.JG.ZS004509 | — | |
| 9 | Centrifugal Motor BC.AG.SS000872 | — | |
| 10 | Screw M25-HC00400040-050020-0003-N YC.WJ.LL000138 | $3.60 | |
| 11 | Screw M30-HC060060-55-85 YC.WJ.L00870 | $2.05 | |
| 12 | Sprinkler Funnel Sealing Ring YC.JG.MY001296 | — | |
| 13 | Sprinkler Funnel YC.JG.ZS004512 | — | |
| 14 | Screw M25-HC00400040-050020-0003-N YC.WJ.LL000138 | $3.60 | |
| 15 | Motor Sealing Ring YC.JG.MY000704 | — | |
| 16 | Sprinkler Funnel Lower Shell YC.JG.ZS004513 | — | |
| 17 | Centrifugal Sprinkler Adapter Cable YC.XC.XX001281 | — | |
| 18 | Screw M30-HC060060-55-85 YC.WJ.L00870 | $2.05 | |
| Sprinkler Thumb Nut YC.JG.ZS006218 | $3.10 | ||
| Centrifugal Sprinkler Lower Disk YC.JG.ZS006219 | $34.60 | ||
| Centrifugal Sprinkler Adapter Cable YC.XC.XX001394 | $31.68 | ||
| Centrifugal Sprinkler Upper Disk YC.JG.ZS007737 | $7.55 | ||
| Sprinkler Soft Hose YC.JG.JS000067 | $1.55 | ||
| Sprinkler Funnel YC.JG.ZS006216 | $43.00 | ||
| Sprinkler Inner Sealing Ring (OD=23.6 mm) YC.JG.MY001829 | $4.55 | ||
| Sprinkler Funnel Bracket YC.JG.ZS006215 | $28.60 | ||
| Centrifugal Motor BC.AG.SS001028 | $453.00 | ||
| Solenoid Valve Module BC.AG.SS001073 | $61.00 | ||
| Spray Lance Bottom Shell YC.JG.ZS006807 | $28.50 | ||
| Spray Lance Outer Shell YC.JG.ZS006356 | $29.95 | ||
| Spring Fixing Piece YC.JG.ZS006592 | $4.85 | ||
| Circlip YC.JG.BJ003348 | $1.00 | ||
| Spray Lance Shaft Sleeve YC.JG.ZS006357 | $18.40 | ||
| Spray Lance Shaft YC.JG.QX004533 | $4.85 | ||
| Compression Spring YC.JG.TT000275 | $4.85 | ||
| Spray Lance Shaft Connector YC.JG.ZS006594 | $28.05 | ||
| Spray Lance Slider YC.JG.ZS006593 | $4.85 | ||
| Spray Lance Shaft Connector Shell (M2 & M4) YC.JG.ZS006808 | $6.65 | ||
| Spray Lance Shaft Connector Shell (M1 & M3) YC.JG.ZS006809 | $6.65 | ||
| Aircraft Arm Hose YC.JG.JS000077 | $18.40 | ||
| Spray Lance Support Rod YC.JG.QX004534 | $30.60 | ||
| Centrifugal Spray Lance Cable YC.XC.XX001460 | $45.30 |
Can't spot your part? Search by part number on the search page or call 1300 916 075.
