T100 Spreading Weight Sensor
Official DJI parts diagram and material list.
Pricing is per single item unless the part description says otherwise.
Parts Diagram
Hover a number to match it with the list. Double-click or use + to zoom.
| No. | Part | $ Each (inc. GST) | |
|---|---|---|---|
| 1 | Weight Sensor Signal Cable YC.XC.XX001402 | $57.00 | |
| 2 | Front Weight Sensor Module BC.AG.SS001118 | $130.00 | |
| 3 | Damping Rubber Pad YC.JG.MY001915 | $1.04 | |
| 4 | Weight Sensor Pin Shaft Washer YC.JG.BJ003735 | $1.04 | |
| 5 | Screw M40-HC00450039-076020-0003-Y YC.ST.LL000112 | $2.00 | |
| 6 | Weight Sensor Pin Shaft YC.JG.QX004544 | $5.06 | |
| 7 | Spread Tank Connector BC.AG.SS001120 | $119.57 | |
| 8 | Screw M40-HC01400140-070039-0003-Y YC.ST.LL000013 | $2.05 | |
| 9 | Landing Gear Hole Plug Rubber YC.JG.MY002073 | $1.10 | |
| 10 | Buckle Hook YC.JG.QX004626 | $31.60 | |
| 11 | Screw (M40-HC02000100-072040-5103-Y) YC.ST.LL000706 | $0.72 | |
| 12 | Rear Weight Sensor Module BC.AG.SS001119 | $137.00 | |
| 13 | Weight Sensor Rubber Cover YC.JG.MY001377 | $9.00 |
Can't spot your part? Search by part number on the search page or call 1300 916 075.
